Ms Pipe

Product Details:
Ms Pipe Price And Quantity
- 1 Container
- 300000-500000 MXN ($)/Container
Ms Pipe Trade Information
- 5-8 Container Per Month
- 10-15 Days
Product Description
We are leading Manufacturers, Supplier, Dealers, and Exporter of ms pipe in India. We stock an extensive range of electric resistance welded (ERW) mild steel pipes/tubes in a size range of 1/2 inch N.B. to 14 inch N.B. in the Light, Medium and Heavy classes, confirming to IS: 1239 (Part-1) 2004, Equivalent to BS: 1387. Our Mild steel pipes are available in different sizes, shapes, and grades. We supply these Pipes in most of the major Indian cities in more than 20 States. We Sachiya Steel International offer different types of grades like Stainless Steel Pipes, Super Duplex Pipes, Duplex Pipes, Carbon Steel Pipes, Alloys Steel Pipes, Nickel Alloys Pipes, Aluminium Pipes, etc.
Sachiya Steel International generates excellent MS pipelines from India. The raw materials of MS Plumbing, ie MS Steel Coils has, were purchased from the renowned steel producer, ie Steel Authority of India (SAIL), which will be a public sector firm and is now the largest integrated steel producer in India. We offer our customers quality flexibility, suppliers and quality merchandise to meet their schedule. Not only are quality goods manufactured by us, but we have a connection with our customers.
Mild Steel Pipes, MS Tubes Dimensions Confirming to IS: 1239 (Part – I) – 2004, Equivalent to BS – 1387 / 1985
Nominal Bore | Outside Diameter | Light (A-Class) Thickness Weight | Medium (B-Class) Thickness Weight | Heavy (C-Class) Thickness Weight | |||||
Inch | mm | Inch | mm | mm | kg/mtr | mm | kg/mtr | mm | kg/mtr |
1/8″ | 3 mm | 0.406 | 10.32 | 1.80 | 0.361 | 2.00 | 2.65 | 0.493 | |
1/4″ | 6 mm | 0.532 | 13.49 | 1.80 | 0.517 | 2.35 | 0.407 | 2.90 | 0.769 |
3/8″ | 10 mm | 0.872 | 17.10 | 1.80 | 0.674 | 2.35 | 0.852 | 2.90 | 1.02 |
1/2″ | 15 mm | 0.844 | 21.43 | 2.00 | 0.952 | 2.65 | 1.122 | 3.25 | 1.45 |
3/4″ | 20 mm | 1.094 | 27.20 | 2.35 | 1.410 | 2.65 | 1.580 | 3.25 | 1.90 |
1″ | 25 mm | 1.312 | 33.80 | 2.65 | 2.010 | 3.25 | 2.440 | 4.05 | 2.97 |
1.1/4″ | 32 mm | 1.656 | 42.90 | 2.65 | 2.580 | 3.25 | 3.140 | 4.05 | 3.84 |
1.1/2″ | 40 mm | 1.906 | 48.40 | 2.90 | 3.250 | 3.25 | 3.610 | 4.05 | 4.43 |
2″ | 50 mm | 2.375 | 60.30 | 2.90 | 4.110 | 3.65 | 5.100 | 4.47 | 6.17 |
2.1/2″ | 65 mm | 3.004 | 76.20 | 3.25 | 5.840 | 3.65 | 6.610 | 4.47 | 7.90 |
3″ | 80 mm | 3.500 | 88.90 | 3.25 | 6.810 | 4.05 | 8.470 | 4.85 | 10.1 |
4″ | 100 mm | 4.500 | 114.30 | 3.65 | 9.890 | 4.50 | 12.10 | 5.40 | 14.4 |
5″ | 125 mm | 5.500 | 139.70 | – | – | 4.85 | 16.20 | 5.40 | 17.8 |
6″ | 150 mm | 6.500 | 165.10 | – | – | 4.85 | 19.20 | 5.40 | 21.2 |
Big Diameter Mild Steel Pipes, MS ERW Pipes Confirming to IS 3589, Grade FE330, Grade FE410
Wall Thickness | Nominal Bore 7″ NB 193.7 mm OD | Nominal Bore 8″ NB 219.1 mm OD | Nominal Bore 10″ NB 273 mm OD | Nominal Bore 12″ NB 323.7 mm OD | Nominal Bore 14″ NB 355.6 mm OD | Nominal Bore 16″ NB 406.4 mm OD | Nominal Bore 18″ NB 457mm OD | Nominal Bore 20″ NB 508 mm OD |
mm | Kg/mtr | Kg/mtr | Kg/mtr | Kg/mtr | Kg/mtr | Kg/mtr | Kg/mtr | Kg/mtr |
4.85 | 22.59 | 25.62 | 32.07 | 38.13 | – | – | – | – |
5.20 | 24.17 | 27.43 | 34.34 | 40.85 | – | – | – | – |
5.60 | 26.00 | 29.28 | 36.93 | 43.93 | 48.11 | – | – | |
6.00 | 27.88 | 31.53 | 39.50 | 47.02 | 51.49 | 61.00 | 69.00 | – |
6.35 | 29.34 | 33.28 | 41.73 | 49.67 | 54.43 | 62.35 | 70.50 | 78.50 |
7.01 | 32.77 | 36.76 | 46.43 | 55.45 | 61.82 | 69.04 | – | – |
7.94 | – | 41.00 | 50.95 | 61.85 | 67.98 | 77.94 | 87.80 | – |
8.18 | – | 42.56 | 53.42 | 65.12 | – | – | – | – |
9.53 | – | 51.50 | 60.24 | 73.75 | 81.21 | 93.13 | 105.00 | 117.00 |
12.70 | – | – | – | – | 107.28 | 123.30 | 139.00 | 155.00 |
MiId Steel Pipes, Tubes Tolerance as per IS:1239
Butt-welded Light tubes | +Not limited |
Medium and Heavy tubes | + Not Limited |
Seamless Tubes | +Not Limited |
Weight
Single tube (light series) | +10 percent |
Single tube | +10 percent |
Mild Steel Pipes, MS Tubes Product, Stock Range
Size | 15mm NB to 150mm NB (1/2” to 6”), 7″ (193.7mm OD to 20″ 508mm OD) |
Dimension & Tolerance | Mild Steel Pipes Dimensions – IS: 1239 (Pt I) – 2004, Equivalent to BS – 1387 / 1985 |
Specifications | IS – 1239 (Part -1) 2004, Equivalent to BS – 1387 / 1985 |
Surface Finish | Black |
Features | High Strength, Corrosion Resistant, High Toughness and Deformability |
Length | As per customer’s requirement (Maximum upto 7 meters) |
Features | High Strength, Corrosion Resistant, High Toughness and Deformability |
